Description
The Faro Focus S350 Plus Laser Scanner represents the forefront of 3D laser scanning technology, delivering unmatched precision and efficiency for professionals in various fields. This advanced device is engineered to capture intricate details with exceptional accuracy, featuring a scanning range of up to 350 meters, making it suitable for both large outdoor areas and complex indoor environments.
With cutting-edge capabilities such as rapid data acquisition and outstanding point cloud quality, the Faro Focus S350 Plus Laser Scanner is an essential tool for architects, engineers, and surveyors aiming to enhance their projects to new levels of excellence. Faro Focus S350 Plus Laser Scanner latest ultra-portable FocusS Laser Scanner series enable to capture fast, straightforward and accurate measurements of complex objects and buildings. The intuitive touch-screen of the FocusS models has been increased in size and clarity to deliver an extraordinary user experience.
Overview
An on-site compensation tool allows data quality optimization on-site. Integrated GPS & GLONASS receiver enable easy positioning. HDR imaging and HD photo resolution ensure true-to-detail scan results with high data quality.
- Distance accuracy up to ±1mm
- Range from 0.6m up to 350m
- IP Class 54
- On-Site Compensation
- Accessory Bay
- HD photo overlay up to 165 megapixel color
Features
- Range up to 350m
Within the Laser Scanner Focus Series, FARO offers its customers the possibility to choose between short, mid and long range laser scanners with the latest technology and high accuracy. - IP Rating – Class 54 and Extensive Temperature Range
With the sealed design, the Focus devices are certified with the industry standard Ingress Protection (IP) Rating and classified in class 54 against environmental influences. In addition scanning in challenging temperature conditions is possible due to an extensive temperature range. - On-site Compensation
With the on-site compensation functionality users can verify and adjust the Focus compensation on-site or in the office, ensuring the highest scan data quality. A comprehensive compensation document is automatically generated. - Integrated Accessory Bay
With this future-proof interface users can connect additional accessories to the scanner, which offers an option for user specific customization. - HDR Photo Overlay
With the Focus HDR functionality, challenging lighting situations will never subtract users’ scan results. Predefined HDR profiles increase the picture quality recorded in very bright or dark environments. - Lightweight and Small Size
Weighing only about 4.2 kg the Focus Laser Scanner is simply mobile and portable.
| SPECIFICATIONS | |
| Range | 0.6 – 350m |
| Measurement Speed | up to 976,000 points/second |
| Ranging Error | ± 1mm |
| Sealed Design | Ingress Protection (IP) Rating Class 54 |
| Angular Accuracy | 19 arc sec for vertical/horizontal angles |
| Integrated Colour Camera | Up to 165 mio. pixel |
| Laser Class | Laser class 1 |
| Weight | 4.2kg |
| Size | 230 x 183 x 103mm |
| Scanner Control | via Touch Screen Display and WLAN |
