Description
The Creaform GoSCAN 50 Scanner product line offers our easiest portable 3D scanning experience, providing fast and reliable measurements. With these handheld 3D scanners, you can even capture 3D data in full color. Their underlying technology accelerates the overall experience: no preparation or specific setup needed, large scanning area, fast measurement, and direct mesh output.
Creaform GoSCAN 50 3D Scanner: they’re very fast, delivering consistent high-quality 3D models in HD color. Through their highly intuitive process, these handheld, self-positioning systems can be used by anyone without prior experience or training.
Features:
3D Scanner Go! SCAN 50 – the top model in the line GO! SCAN company Creaform. This is a mobile and easy-to-use device designed primarily for 3D-scanning medium and large sites (ranging from 0.3 to 3 meters). GO! SCAN 50 is characterized by high speed, the ability to transmit the color and geometry of the object, a great autonomy and ease of use.
Technology of 3D-scanning
- Laser: Laser triangulation phase
- Light source: Light-emitting diode
| Specification | |
| Accuracy | Up to 0.100 mm (0.004 in.) |
| Volumetric accuracy | 0.300 mm/m (0.0036 in./ft) |
| Resolution | 0.100 mm (0.004 in.) |
| Measurement rate | 550,000 measurements/s |
| Light source | White light (LED) |
| Positioning methods | Geometry and/or color and/or targets |
| Scanning area | 143 x 108 mm (5.6 in x 4.3 in) |
| Stand-off distance | 380 mm (15 in.) |
| Depth of field | 100 mm (4 in.) , 250 mm (10 in.) |
| Part size range (recommended) | 0.05 – 0.5 m (2 – 20 in.) |
| Texture resolution | 50 to 250 DPI |
| Texture colors | 24 bits |
| Software | VXelements |
| Output formats | .dae, .fbx, .ma, .obj, .ply, .stl, .txt, .wrl, .x3d, .x3dz, .zpr |
| Compatible software | 3D Systems (Geomagic® Solutions), InnovMetric Software (PolyWorks), Dassault Systèmes (CATIA V5 and SolidWorks), PTC (Pro/ENGINEER), Siemens (NX and Solid Edge), Autodesk (Inventor, Alias, 3ds Max, Maya, Softimage). |
| Weight | 930 g (2.05 lbs.) |
| Dimensions | 154 x 178 x 235 mm (6 x 7 x 9.2 in.) |
| Connection standard | 1 x USB 2.0 |
| Operating temperature range | 15-40 °C (41-104 °F) |
