Description
The Creaform Handyscan Black Elite Portable 3D Scanners is a cutting-edge 3D laser scanner that revolutionizes the way professionals capture and analyze complex geometries. With its advanced technology, this portable device offers unparalleled accuracy and speed, making it an essential tool for industries such as aerospace, automotive, and manufacturing.
The Creaform Handyscan Black Elite Portable 3D Scanners is designed for ease of use, allowing operators to quickly scan objects of various sizes and shapes without the need for extensive setup or calibration. Its lightweight and ergonomic design ensures that users can maneuver it effortlessly, even in challenging environments. By integrating this state-of-the-art scanner into your workflow, you can significantly enhance your productivity and achieve precise measurements that drive innovation and quality in your projects.
Creaform Handyscan Black Elite 3D Scanner
The HandySCAN 3D BLACK Series technical specifications make it the reference in high-end, portable 3D measurement technology. Featuring accuracy, simplicity, portability, and unmatched measurement speed, they capture high-quality measuring data regardless of environmental changes or part movement. Thanks to this 3D scanner’s specifications like accuracy, measurement rate, high resolution, and software compatibility, it is an ideal tool for production quality assurance and product development applications.
Accurate, Portable, Simple and Fast
The HandySCAN 3D product range is the standard against which all other portable metrology‑grade 3D scanners are measured. Constant refinement makes this third-generation device a finely-honed instrument. It meets or exceeds the requirements of design, manufacturing and metrology professionals who want an efficient and dependable way to record precise 3D measurements of a physical object in any location.
3D scanning technology
HandySCAN BLACK 3D scanners use blue light laser technology for enhanced accuracy. The Elite version works with 11 laser crosses generated by 2 laser sources. An additional single laser line mode is available for scanning intricate zones with low visibility.
The HandySCAN BLACK Elite also relies on photogrammetry technology to position itself in space, with the help of targets (stickers). These markers can be placed either on the part itself or its immediate surroundings.
Accuracy
- 0.025 mm (0.0009 in)
- 0.012 mm (0.0005 in) with Limited Edition
- Volumetric accuracy
- 0.020 0.040 mm/m (0.0008 in 0.0005 in/ft)
- 0.012 mm 0.020mm/m (0.0005 in 0.0002 in/ft) with Limited Edition
- Reliable acceptance test
- Based on VDI/VDE 2634 part 3 standard
- ISO 17025 accredited laboratory
- High resolution for fine details
- Integrated photogrammetry
- High accuracy on large measurements with volumetric accuracy optimization
Faster 3D Scanning Process
The HandySCAN 3D|BLACK Series supports automatic mesh generation, streamlining the workflow from setup to scan to mesh. Its Flex Volume feature also allows for rapid, high-quality measurements of large parts from a distance and precise scanning of smaller parts at a closer range.
- Flexible working distance: 0.3m (1 ft) to 2.5m (8.2 ft) for faster acquisition
- High measurement rate: Up to 1,800,000 measurements/s
- Large scanning area of 30 blue laser lines
- Quick setup: Up-and-running in less than 2 minutes
Simplicity and Versatility
With its user-friendly interface and ergonomic design, this 3D measurement solution is easy-to-use and has a short learning curve. Its versatility gives the opportunity to scan various object sizes and surface types in real time—all with the same device.
