Description
The new FARO Focus3D X 330 a high-speed 3D Laser Scanner with extra-long range. The Focus3D X advances into entirely new dimensions: it can scan objects up to 330 meters away even in direct sunlight. With its integrated GPS receiver, the laser scanner is able to correlate individual scans in post-processing making it ideal for surveying based applications.
Benefits
The new Faro Focus3D X 330 Laser Scanner is the leading tool for surveying and 3D documentation. Scanning range – 330m, integrated GPS, the possibility to work in direct sunlight as well as the specially for the scanner designed protection cover make it a ideal tool for outdoor enviroments.
Features
- Features include eye-safe laser, automatic adaption of brightness, easy positioning, co-axial design parallax, Class 1 laser, WLAN remote control, and low noise performance. Used for measuring distance, dimensions, area, and volume.
- Suitable for reconstruction, architecture, forensics, surveying, inspection, analyzing and 3D documentation applications.
- Specifications include up to 976000 points/second measurement speed, +/-2 mm error range, 70 MP color resolution, 360 x 300 degrees field of view, 0.009 x 0.009 degrees step size, 5820 rpm vertical scan speed, 1550 nm wavelength, 0.19 mrad beam divergence, 2.25 mm beam diameter at exit, 0.015 degree dual-axis compensator, and 4.5 hours of battery runtime per charge.
- Equipped with an integrated GPS receiver to correlate individual scans in post-processing, height sensor, touchscreen display, compass and SD storage. Available in sealed design with a high operating temperature range.
- Range Focus3D X 330: 0.6 – 330m
- Measurement speed: up to 976,000 points/second
- Distance accuracy/ranging error: ± 2mm
- Integrated color camera: Up to 70 million pixels
- Laser class: Laser class 1
- Noise reduction 50%
- Weight: 5.2kg
- Multi-Sensor: GPS, Compass, Height Sensor, Dual Axis Compensator
- Size: 240 x 200 x 100mm
- Scanner control: via touchscreen display and WLAN
