Description
The GE Vscan Air CL Portable Handheld Ultrasound is a versatile, high-performance, handheld ultrasound device that enhances point-of-care diagnostics, guided procedures, and routine examinations in various clinical settings.
Its key features, such as wireless connectivity, dual-probe design, high-resolution imaging, portability, and ease of use, make it invaluable for improving diagnostic accuracy, efficiency, and overall patient care. The GE Vscan Air CL Portable Handheld Ultrasound is a cost-effective, robust, and user-friendly solution for modern healthcare environments.
Key Features:
- Wireless Connectivity: The Vscan Air CL is completely wireless, eliminating the need for cables and providing more flexibility during examinations.
- Dual Probe Design: Features both a linear and a curved transducer in one probe, allowing for a wide range of applications from shallow to deep imaging.
- High-Resolution Imaging: Delivers crystal-clear images that help in accurate diagnosis and assessment.
- Portability: Compact and lightweight, making it easy to carry and use in various settings within the clinic or in the field.
- User-Friendly Interface: Intuitive app-based interface compatible with both iOS and Android devices.
- Long Battery Life: Provides extended usage time, ensuring the device is ready when needed.
- Robust Security: Encrypted data transfer ensures patient information is secure.
- Durability: Built to withstand daily use in a medical environment, including being dropped or exposed to fluids.
Technical Data:
- B-mode
- Colour Doppler
- Harmonic Imaging mode
- Convex probe: frequency 2 – 5 MHz, average frequency 3.3 MHz, maximum depth: 24 cm (64 x 16 mm lens)
- Linear probe: frequency 3 – 12 MHz, average frequency 7.7 MHz, maximum depth: 8 cm (40 x 7 mm lens)
- Charging time: approx. 75 minutes
- Protection class: IP67
- High temperature resistance
- Size: 64 x 131 x 31 mm (W x H x D), weight: approx. 205 g
- Scan time – up to 50 minutes
- Recharge time – 75 minutes (from 10% to 90%)
- Use any Qi compliant wireless charger
- Tested to military drop standards (MIL-810G)2
- IP67 rated waterproof2
- Compatible with high-level disinfection techniques
- Withstands temperature extremes
- Frequency 2 – 5 MHz
- Maximum depth – 24 cm
