Description
As a portable ultrasound scanner, the Philips CX50 Portable Ultrasound System is very easy to move from one department to another. It is as well integrated in emergency departments as in operating theatres where space is limited and already highly congested.
The Philips CX50 Portable Ultrasound System established itself as the Gold Standard of portable cardiac ultrasound machines, and continued updates keep the system relevant in the refurbished portable cardiovascular ultrasound market. Premium technologies bring a new level of image quality to compact ultrasound so performance isn’t sacrificed for portability. Designed for critical study requirements and big system performance everywhere you need it.
This premium portable machine is known best for its cardiac imaging and advanced imaging features unavailable on other systems. However, Philips CX50 Portable Ultrasound System also excels as a fully shared service system, which makes it ideal in larger practices, hospitals, emergency departments, or other point of care situations.
Features
- PureWave Everywhere
- Wireless & wired DICOM for connectivity in any environment
- Expand diagnostic information
- Portable ultrasound when fast action is needed
- Digital broadband beamforming on a compact
- On cart
- SonoCT brings a new level of image quality
- SmartExam reduces exam time by up to 50%*
- Remote travel
- XRES brings a new level of clarity to compact ultrasound
- Fine‐tune exams with active native data
- Premium performance in the surgery suite
The CX50 offers 4D imaging in cardiology using the X7-2t xMatrix probe. It does not, however, have a 4D application in gynaecology/obstetrics. It remains a highly reliable device with powerful, high-quality imaging. The integrated features also allow better treatment of difficult-to-image patients.
SPECIFICATIONS | |
Dimensions and Weight | |
Height | 86 mm (3.4 in) |
Width | 413 mm (16.25 in) |
Depth | 356 mm (14 in) |
Weight | 7.3 kg (16.2 lbs.), approx. 43 lbs. with packaging |
Electrical Power | |
Voltage | 100-240V |
Frequency | 50/60 Hz |
Amperage | 2.65A MAX |
Heat dissipation | 700-1100 BTU/hour (fully loaded) |
Operation range | 10°C – 40°C operating in 15-95% relative humidity |
Next-generation all-digital compact broadband beamformer with pulse shaping capability. | |
Up to 504,576 digitally-processed channels. | |
Image presentation | Depth from 1 cm to 30 cm (transducer dependent). |
Up to 170 dB full-time system dynamic range. |
